Buzzer
Buzzers in high quality for compact and cost-efficient acoustic signaling. Our portfolio includes piezoelectric and magnetic versions in different form factors, sound levels and voltage ranges. Suitable for industrial electronics, medical technology, building automation, household appliances and series products requiring clear acoustic warning or notification tones.
|
|
||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| DIGISOUND | Panelmontage | 5-28 Vdc | 18 mA | 3000 Hz | 85 dB/10cm | – | Ø 32 mm | 40 g | – | – | -20 °C | 65 °C | 0.01 g | |
| DIGISOUND | Panelmontage | 5-28 Vdc | 20 mA | 2900 Hz | 85 dB/10cm | – | Ø 29 mm | 40 g | – | – | -20 °C | 75 °C | 0.04 g | |
| DIGISOUND | Panelmontage | 5-28 Vdc | 20 mA | 2900 Hz | 85 dB/10cm | – | Ø 29 mm | 40 g | – | – | -20 °C | 75 °C | 0.01 g | |
| DIGISOUND | Panelmontage | 5-28 Vdc | 20 mA | 2900 Hz | 80 dB/10cm | – | Ø 27 mm | 13 g | – | – | -30 °C | 65 °C | 0.01 g | |
| DIGISOUND | Panelmontage | 5-28 Vdc | 18 mA | 3000 Hz | 85 dB/10cm | – | Ø 32 mm | 40 g | – | – | -20 °C | 65 °C | 0.01 g | |
| DIGISOUND | Panelmontage | 5-28 Vdc | 20 mA | 2900 Hz | 85 dB/10cm | – | Ø 29 mm | 40 g | – | – | -20 °C | 75 °C | 0.01 g | |
| DIGISOUND | Panelmontage | 5-28 Vdc | 20 mA | 2900 Hz | 95 dB/10cm | – | Ø 29 mm | 40 g | – | – | -20 °C | 75 °C | 0.01 g | |
| DIGISOUND | Panelmontage | 8-31 Vdc | 16 mA | 2900 Hz | 78 dB/10cm | – | Ø 27 mm | 14 g | – | – | -30 °C | 65 °C | 0.01 g | |
| DIGISOUND | Panelmontage | 12-50 Vdc | 6 mA | 3000 Hz | 85 dB/10cm | – | Ø 29 mm | 50 g | – | – | -40 °C | 75 °C | 0.01 g | |
| DIGISOUND | Panelmontage | 5-28 Vdc | 18 mA | 3000 Hz | 85 dB/10cm | – | Ø 32 mm | 40 g | – | – | -20 °C | 60 °C | 0.01 g | |
| Compro Electronic | Magnetisch | 3-8 Vdc | 40 mA | 2400 Hz | 85 dB/10cm | PIN | – | 2 g | – | – | -30 °C | 70 °C | 0.01 g | |
| Compro Electronic | Magnetisch | 1.5 Vdc | 30 mA | 2048 Hz | 85 dB/10cm | PIN | 12 x 8,5 mm | 2 g | – | – | -30 °C | 75 °C | 0.01 g | |
| Compro Electronic | Magnetisch | 1-5 Vdc | 40 mA | 2000 Hz | 85 dB/10cm | – | 12x8,5 mm | 2 g | – | – | -20 °C | 60 °C | 0.01 g | |
| Compro Electronic | Magnetisch | 3-8 Vdc | 40 mA | 2400 Hz | 85 dB/10cm | – | 12x9 mm | 2 g | – | – | -40 °C | 85 °C | 0.01 g | |
| DIGISOUND | – | 8-17,5 Vdc | 40 mA | 95 Hz | – | – | 2000 mm | – | – | – | -40 °C | 85 °C | 0.01 g | |
| DIGISOUND | SMD | 8-17,5 Vdc | 40 mA | 2000 Hz | 95 dB/10cm | – | – | 2 g | – | – | -40 °C | 85 °C | 0.01 g | |
| DIGISOUND | – | 8-17,5 Vdc | 40 mA | 95 Hz | – | – | 2000 mm | – | – | – | -40 °C | 85 °C | 0.01 g | |
| DIGISOUND | – | 8-17,5 Vdc | 40 mA | 95 Hz | – | – | 2000 mm | – | – | – | -40 °C | 85 °C | 0.01 g | |
| DIGISOUND | – | – | – | – | – | – | – | – | – | – | – | – | 0.01 g | |
| DIGISOUND | – | – | – | – | – | – | – | – | – | – | – | – | 0.01 g | |
| DIGISOUND | SMD | 3-16 Vdc | 100 mA | 4000 Hz | 80 dB/10cm | SMD | 14 x 14 mm | 2.3 g | – | – | -40 °C | 85 °C | 0.01 g | |
| DIGISOUND | – | – | – | – | – | – | – | – | – | – | – | – | 0.01 g | |
| DIGISOUND | – | 9-16 Vdc | 15 mA | – | – | – | 3300 mm | – | – | – | -30 °C | 85 °C | 0.01 g | |
| DIGISOUND | – | 2,4-36 Vdc | 15 mA | 2900 Hz | 90 dB/10cm | – | – | 4.7 g | – | – | -20 °C | 60 °C | 0.01 g | |
| DIGISOUND | – | 9-16 Vdc | 15 mA | – | – | – | 3300 mm | – | – | – | -30 °C | 85 °C | 0.01 g | |
| DIGISOUND | – | 9-16 Vdc | 15 mA | – | – | – | 3300 mm | – | – | – | -30 °C | 85 °C | 0.01 g | |
| DIGISOUND | – | 9-16 Vdc | 15 mA | – | – | – | 3300 mm | – | – | – | -30 °C | 85 °C | 0.01 g | |
| DIGISOUND | Piezo | – | – | – | – | – | – | – | – | – | – | – | 0.01 g | |
| DIGISOUND | – | 3-25 Vdc | 5 mA | 4000 Hz | 75 dB/10cm | SMD | – | 0.4 g | – | – | -30 °C | 85 °C | 0.01 g | |
| DIGISOUND | Piezo | 1,5-15 Vdc | 30 mA | 2900 Hz | 105 dB/10cm | PIN | Ø45 mm | 21 g | – | – | -20 °C | 70 °C | 0.01 g | |
| DIGISOUND | Piezo | 3-18 Vdc | 30 mA | 2900 Hz | 105 dB/10cm | PIN | Ø45 mm | 21 g | – | – | -20 °C | 70 °C | 0.01 g | |
| DIGISOUND | Piezo | 12 Vdc | 15 mA | 3300 Hz | 90 dB/10cm | – | 23,9 x 9,5 mm | 3 g | – | – | -20 °C | 70 °C | 0.01 g | |
| DIGISOUND | Piezo | 3-16 Vdc | 12 mA | 4000 Hz | 85 dB/10cm | – | 13,8 x 7,5 mm | 0.8 g | – | – | -20 °C | 70 °C | 0.01 g | |
| DIGISOUND | Piezo | 3-15 Vdc | 13 mA | 4000 Hz | 83 dB/10cm | – | – | – | – | – | -20 °C | 70 °C | 0.01 g | |
| DIGISOUND | Piezo | 2-5 Vdc | 60 mA | 2731 Hz | 90 dB/10cm | LEAD | – | 0.8 g | – | – | -25 °C | 70 °C | 0.01 g | |
| DIGISOUND | Piezo | 3-20 Vdc | 12 mA | 3800 Hz | 90 dB/10cm | – | Ø 23 mm | 4 g | – | – | -20 °C | 70 °C | 0.01 g | |
| DIGISOUND | Magnetisch | 4-8 Vdc | 30 mA | 2200 Hz | 90 dB/10cm | PIN | Ø16 mm | 3 g | – | – | -20 °C | 70 °C | 0.01 g | |
| DIGISOUND | Magnetisch | 8-16 Vdc | 30 mA | 2200 Hz | 85 dB/10cm | – | – | 2 g | – | – | -40 °C | 85 °C | 0.01 g | |
| DIGISOUND | Piezo | 6-30 Vdc | 35 mA | 3000 Hz | 97 dB/10cm | WIRE | – | 88 g | – | – | -20 °C | 80 °C | 0.01 g | |
| DIGISOUND | Mechanisch | 4-8 Vdc | 25 mA | 400 Hz | 75 dB/10cm | PIN | 16 x 22,5 mm | 8.5 g | – | – | -40 °C | 85 °C | 0.01 g | |
| DIGISOUND | Mechanisch | 9-15 Vdc | 25 mA | 400 Hz | 75 dB/10cm | – | – | 8.5 g | – | – | -40 °C | 85 °C | 0.01 g | |
| DIGISOUND | Mechanisch | 9-15 Vdc | 25 mA | 400 Hz | 75 dB/10cm | – | – | 8.5 g | – | – | -40 °C | 85 °C | 0.01 g | |
| DIGISOUND | Mechanisch | 4-8 Vdc | 33 mA | 400 Hz | 75 dB/10cm | WIRE | Ø32 x 17,6 mm | 16 g | – | – | -40 °C | 80 °C | 0.01 g | |
| DIGISOUND | Mechanisch | 7-16 Vdc | 23 mA | 400 Hz | 75 dB/10cm | WIRE | Ø32 x 17,6 mm | 16 g | – | – | -40 °C | 80 °C | 0.01 g | |
| DIGISOUND | Mechanisch | 20-28 Vdc | 21 mA | 400 Hz | 75 dB/10cm | WIRE | Ø 32 x 17,6 mm | 16 g | – | – | -40 °C | 80 °C | 0.01 g | |
| DIGISOUND | Mechanisch | 4-8 Vdc | 35 mA | 400 Hz | 92 dB/10cm | PIN | 26 x 26 mm | 16 g | – | – | -40 °C | 70 °C | 0.01 g | |
| DIGISOUND | Mechanisch | 20-28 Vdc | 35 mA | 400 Hz | 92 dB/10cm | PIN | 26 x 26 mm | 16 g | – | – | -40 °C | 70 °C | 0.01 g | |
| DIGISOUND | Mechanisch | 2-5 Vdc | 15 mA | 400 Hz | 75 dB/10cm | – | – | 10 g | – | – | -20 °C | 60 °C | 0.01 g |
