2.5" SSDs
2.5-inch SSDs are available in different interfaces, capacities and NAND flash types and cover many industrial and embedded applications. Versions with extended temperature range are available for industrial use. Ideal for systems requiring an established form factor, robust storage technology and easy integration.
|
|
||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Flexxon | CLASSIC II | 2.5 Inch | SLC | Standard ATA/DIE | 1 GB | 75 MB/s | 86 MB/s | 5 V | 2000000 | 2000G/0.3ms | 80Hz ~ 2000Hz/20G | Yes | No | No | No | 100 mm | 70 mm | 9.5 mm | -40 °C | 85 °C | 0.01 g | |
| Flexxon | CLASSIC II | 2.5 Inch | MLC | Standard ATA/DIE | 1000 GB | 75 MB/s | 86 MB/s | 5 V | 2000000 | 2000G/0.3ms | 80Hz ~ 2000Hz/20G | Yes | No | No | No | 100 mm | 70 mm | 9.5 mm | -40 °C | 85 °C | 0.01 g | |
| Flexxon | CLASSIC II | 2.5 Inch | SLC | Standard ATA/DIE | 2 GB | 75 MB/s | 86 MB/s | 5 V | 2000000 | 2000G/0.3ms | 80Hz ~ 2000Hz/20G | Yes | No | No | No | 100 mm | 70 mm | 9.5 mm | -40 °C | 85 °C | 0.01 g | |
| Flexxon | CLASSIC II | 2.5 Inch | MLC | Standard ATA/DIE | 4 GB | 75 MB/s | 86 MB/s | 5 V | 2000000 | 2000G/0.3ms | 80Hz ~ 2000Hz/20G | Yes | No | No | No | 100 mm | 70 mm | 9.5 mm | -40 °C | 85 °C | 0.01 g | |
| Flexxon | CLASSIC II | 2.5 Inch | SLC | Standard ATA/DIE | 4 GB | 75 MB/s | 86 MB/s | 5 V | 2000000 | 2000G/0.3ms | 80Hz ~ 2000Hz/20G | Yes | No | No | No | 100 mm | 70 mm | 9.5 mm | -40 °C | 85 °C | 0.01 g | |
| Flexxon | CLASSIC II | 2.5 Inch | MLC | Standard ATA/DIE | 8 GB | 75 MB/s | 86 MB/s | 5 V | 2000000 | 2000G/0.3ms | 80Hz ~ 2000Hz/20G | Yes | No | No | No | 100 mm | 70 mm | 9.5 mm | -40 °C | 85 °C | 0.01 g | |
| Flexxon | CLASSIC II | 2.5 Inch | pSLC | Standard ATA/DIE | 8 GB | 75 MB/s | 86 MB/s | 5 V | 2000000 | 2000G/0.3ms | 80Hz ~ 2000Hz/20G | Yes | No | No | No | 100 mm | 70 mm | 9.5 mm | -40 °C | 85 °C | 0.01 g | |
| Flexxon | CLASSIC II | 2.5 Inch | SLC | Standard ATA/DIE | 8 GB | 75 MB/s | 86 MB/s | 5 V | 2000000 | 2000G/0.3ms | 80Hz ~ 2000Hz/20G | Yes | No | No | No | 100 mm | 70 mm | 9.5 mm | -40 °C | 85 °C | 0.01 g | |
| Flexxon | CLASSIC II | 2.5 Inch | MLC | Standard ATA/DIE | 16 GB | 75 MB/s | 86 MB/s | 5 V | 2000000 | 2000G/0.3ms | 80Hz ~ 2000Hz/20G | Yes | No | No | No | 100 mm | 70 mm | 9.5 mm | -40 °C | 85 °C | 0.01 g | |
| Flexxon | CLASSIC II | 2.5 Inch | pSLC | Standard ATA/DIE | 16 GB | 75 MB/s | 86 MB/s | 5 V | 2000000 | 2000G/0.3ms | 80Hz ~ 2000Hz/20G | Yes | No | No | No | 100 mm | 70 mm | 9.5 mm | -40 °C | 85 °C | 0.01 g | |
| Flexxon | CLASSIC II | 2.5 Inch | SLC | Standard ATA/DIE | 16 GB | 75 MB/s | 86 MB/s | 5 V | 2000000 | 2000G/0.3ms | 80Hz ~ 2000Hz/20G | Yes | No | No | No | 100 mm | 70 mm | 9.5 mm | -40 °C | 85 °C | 0.01 g | |
| Flexxon | CLASSIC II | 2.5 Inch | MLC | Standard ATA/DIE | 32 GB | 75 MB/s | 86 MB/s | 5 V | 2000000 | 2000G/0.3ms | 80Hz ~ 2000Hz/20G | Yes | No | No | No | 100 mm | 70 mm | 9.5 mm | -40 °C | 85 °C | 0.01 g | |
| Flexxon | CLASSIC II | 2.5 Inch | pSLC | Standard ATA/DIE | 32 GB | 75 MB/s | 86 MB/s | 5 V | 2000000 | 2000G/0.3ms | 80Hz ~ 2000Hz/20G | Yes | No | No | No | 100 mm | 70 mm | 9.5 mm | -40 °C | 85 °C | 0.01 g | |
| Flexxon | CLASSIC II | 2.5 Inch | SLC | Standard ATA/DIE | 32 GB | 75 MB/s | 86 MB/s | 5 V | 2000000 | 2000G/0.3ms | 80Hz ~ 2000Hz/20G | Yes | No | No | No | 100 mm | 70 mm | 9.5 mm | -40 °C | 85 °C | 0.01 g | |
| Flexxon | CLASSIC II | 2.5 Inch | MLC | Standard ATA/DIE | 64 GB | 75 MB/s | 86 MB/s | 5 V | 2000000 | 2000G/0.3ms | 80Hz ~ 2000Hz/20G | Yes | No | No | No | 100 mm | 70 mm | 9.5 mm | -40 °C | 85 °C | 0.01 g | |
| Flexxon | CLASSIC II | 2.5 Inch | pSLC | Standard ATA/DIE | 64 GB | 75 MB/s | 86 MB/s | 5 V | 2000000 | 2000G/0.3ms | 80Hz ~ 2000Hz/20G | Yes | No | No | No | 100 mm | 70 mm | 9.5 mm | -40 °C | 85 °C | 0.01 g | |
| Flexxon | CLASSIC II | 2.5 Inch | SLC | Standard ATA/DIE | 64 GB | 75 MB/s | 86 MB/s | 5 V | 2000000 | 2000G/0.3ms | 80Hz ~ 2000Hz/20G | Yes | No | No | No | 100 mm | 70 mm | 9.5 mm | -40 °C | 85 °C | 0.01 g | |
| Flexxon | CLASSIC II | 2.5 Inch | MLC | Standard ATA/DIE | 128 GB | 75 MB/s | 86 MB/s | 5 V | 2000000 | 2000G/0.3ms | 80Hz ~ 2000Hz/20G | Yes | No | No | No | 100 mm | 70 mm | 9.5 mm | -40 °C | 85 °C | 0.01 g | |
| Flexxon | CLASSIC II | 2.5 Inch | pSLC | Standard ATA/DIE | 128 GB | 75 MB/s | 86 MB/s | 5 V | 2000000 | 2000G/0.3ms | 80Hz ~ 2000Hz/20G | Yes | No | No | No | 100 mm | 70 mm | 9.5 mm | -40 °C | 85 °C | 0.01 g | |
| Flexxon | CLASSIC II | 2.5 Inch | SLC | Standard ATA/DIE | 128 GB | 75 MB/s | 86 MB/s | 5 V | 2000000 | 2000G/0.3ms | 80Hz ~ 2000Hz/20G | Yes | No | No | No | 100 mm | 70 mm | 9.5 mm | -40 °C | 85 °C | 0.01 g | |
| Flexxon | CLASSIC II | 2.5 Inch | MLC | Standard ATA/DIE | 256 GB | 75 MB/s | 86 MB/s | 5 V | 2000000 | 2000G/0.3ms | 80Hz ~ 2000Hz/20G | Yes | No | No | No | 100 mm | 70 mm | 9.5 mm | -40 °C | 85 °C | 0.01 g | |
| Flexxon | CLASSIC II | 2.5 Inch | MLC | Standard ATA/DIE | 512 GB | 75 MB/s | 86 MB/s | 5 V | 2000000 | 2000G/0.3ms | 80Hz ~ 2000Hz/20G | Yes | No | No | No | 100 mm | 70 mm | 9.5 mm | -40 °C | 85 °C | 0.01 g | |
| Flexxon | XTREME | 2.5 Inch | 3D TLC | SATA III 6Gbps | 1000 GB | 500 MB/s | 550 MB/s | 5 V | 2000000 | 1500G/0.5ms | 80Hz ~ 2000Hz/20G | No | No | No | No | 100 mm | 69.85 mm | 7 mm | – | 70 °C | 0.01 g | |
| Flexxon | XCEL | 2.5 Inch | 3D TLC | SATA III 6Gbps | 1000 GB | 530 MB/s | 550 MB/s | 5 V | 2000000 | 1500G/0.5ms | 80Hz ~ 2000Hz/20G | No | No | No | No | 100 mm | 69.85 mm | 7 mm | – | 70 °C | 0.01 g | |
| Flexxon | INSPIRE | 2.5 Inch | 3D TLC | SATA III 6Gbps | 1000 GB | 521 MB/s | 565 MB/s | 5 V | 2000000 | 1500G/0.5ms | 80Hz ~ 2000Hz/20G | Yes | No | No | No | 100 mm | 69.85 mm | 7 mm | -40 °C | 85 °C | 0.01 g | |
| Flexxon | INSPIRE | 2.5 Inch | 3D TLC | SATA III 6Gbps | 1000 GB | 521 MB/s | 565 MB/s | 5 V | 2000000 | 1500G/0.5ms | 80Hz ~ 2000Hz/20G | Yes | No | No | Yes | 100 mm | 69.85 mm | 7 mm | -40 °C | 85 °C | 0.01 g | |
| Flexxon | XTREME | 2.5 Inch | 3D TLC | SATA III 6Gbps | 1000 GB | 500 MB/s | 550 MB/s | 5 V | 2000000 | 1500G/0.5ms | 80Hz ~ 2000Hz/20G | Yes | No | No | No | 100 mm | 69.85 mm | 7 mm | -40 °C | 85 °C | 0.01 g | |
| Flexxon | INSPIRE | 2.5 Inch | 3D TLC | SATA III 6Gbps | 1000 GB | 521 MB/s | 565 MB/s | 5 V | 2000000 | 1500G/0.5ms | 80Hz ~ 2000Hz/20G | Yes | No | No | No | 100 mm | 69.85 mm | 7 mm | – | 70 °C | 0.01 g | |
| Flexxon | INSPIRE | 2.5 Inch | 3D TLC | SATA III 6Gbps | 1000 GB | 521 MB/s | 565 MB/s | 5 V | 2000000 | 1500G/0.5ms | 80Hz ~ 2000Hz/20G | Yes | No | No | Yes | 100 mm | 69.85 mm | 7 mm | – | 70 °C | 0.01 g | |
| Flexxon | XTREME | 2.5 Inch | 3D TLC | SATA III 6Gbps | 1000 GB | 500 MB/s | 550 MB/s | 5 V | 2000000 | 1500G/0.5ms | 80Hz ~ 2000Hz/20G | Yes | No | No | No | 100 mm | 69.85 mm | 7 mm | – | 70 °C | 0.01 g | |
| Flexxon | ACHIEVER Pro | 2.5 Inch | MLC | SATA III 6Gbps | 1000 GB | 420 MB/s | 470 MB/s | 5 V | 2000000 | 1500G/0.5ms | 80Hz ~ 2000Hz/20G | Yes | No | No | No | 100 mm | 69.85 mm | 7 mm | -40 °C | 85 °C | 0.01 g | |
| Flexxon | GALAXY | 2.5 Inch | MLC | SATA III 6Gbps | 1000 GB | 440 MB/s | 520 MB/s | 5 V | 3000000 | 1500G/0.5ms | 50G, 11ms | 10Hz ~ 2000Hz/16.4G | Yes | No | Yes | No | 100 mm | 70 mm | 9.5 mm | -40 °C | 85 °C | 0.01 g | |
| Flexxon | ACHIEVER Pro | 2.5 Inch | MLC | SATA III 6Gbps | 1000 GB | 420 MB/s | 470 MB/s | 5 V | 2000000 | 1500G/0.5ms | 80Hz ~ 2000Hz/20G | Yes | No | No | Yes | 100 mm | 69.85 mm | 7 mm | -40 °C | 85 °C | 0.01 g | |
| Flexxon | ACHIEVER Pro | 2.5 Inch | MLC | SATA III 6Gbps | 1000 GB | 420 MB/s | 470 MB/s | 5 V | 2000000 | 1500G/0.5ms | 80Hz ~ 2000Hz/20G | Yes | No | No | No | 100 mm | 69.85 mm | 7 mm | – | 70 °C | 0.01 g | |
| Flexxon | GALAXY | 2.5 Inch | MLC | SATA III 6Gbps | 1000 GB | 440 MB/s | 520 MB/s | 5 V | 3000000 | 1500G/0.5ms | 50G, 11ms | 10Hz ~ 2000Hz/16.4G | Yes | No | Yes | No | 100 mm | 70 mm | 9.5 mm | – | 70 °C | 0.01 g | |
| Flexxon | ACHIEVER Pro | 2.5 Inch | MLC | SATA III 6Gbps | 1000 GB | 420 MB/s | 470 MB/s | 5 V | 2000000 | 1500G/0.5ms | 80Hz ~ 2000Hz/20G | Yes | No | No | Yes | 100 mm | 69.85 mm | 7 mm | – | 70 °C | 0.01 g | |
| Flexxon | XTREME | 2.5 Inch | pSLC | SATA III 6Gbps | 2 GB | 50 MB/s | 160 MB/s | 5 V | 2000000 | 1500G/0.5ms | 80Hz ~ 2000Hz/20G | No | No | No | No | 100 mm | 69.85 mm | 7 mm | – | 70 °C | 0.01 g | |
| Flexxon | XTREME | 2.5 Inch | pSLC | SATA III 6Gbps | 2 GB | 50 MB/s | 160 MB/s | 5 V | 2000000 | 1500G/0.5ms | 80Hz ~ 2000Hz/20G | Yes | No | No | No | 100 mm | 69.85 mm | 7 mm | -40 °C | 85 °C | 0.01 g | |
| Flexxon | XTREME | 2.5 Inch | pSLC | SATA III 6Gbps | 2 GB | 50 MB/s | 160 MB/s | 5 V | 2000000 | 1500G/0.5ms | 80Hz ~ 2000Hz/20G | Yes | No | No | No | 100 mm | 69.85 mm | 7 mm | – | 70 °C | 0.01 g | |
| Flexxon | VALUE | 2.5 Inch | SLC | SATA II 3Gbps | 2 GB | 30 MB/s | 40 MB/s | 5 V | 2000000 | 1500G/0.5ms | 80Hz ~ 2000Hz/20G | Yes | No | No | No | 100 mm | 69.85 mm | 7 mm | -40 °C | 85 °C | 0.01 g | |
| Flexxon | VALUE | 2.5 Inch | SLC | SATA II 3Gbps | 2 GB | 30 MB/s | 40 MB/s | 5 V | 2000000 | 1500G/0.5ms | 80Hz ~ 2000Hz/20G | Yes | No | No | No | 100 mm | 69.85 mm | 7 mm | – | 70 °C | 0.01 g | |
| Flexxon | XCEL | 2.5 Inch | 3D TLC | SATA III 6Gbps | 2000 GB | 530 MB/s | 550 MB/s | 5 V | 2000000 | 1500G/0.5ms | 80Hz ~ 2000Hz/20G | No | No | No | No | 100 mm | 69.85 mm | 7 mm | – | 70 °C | 0.01 g | |
| Flexxon | INSPIRE | 2.5 Inch | 3D TLC | SATA III 6Gbps | 2000 GB | 520 MB/s | 565 MB/s | 5 V | 2000000 | 1500G/0.5ms | 80Hz ~ 2000Hz/20G | Yes | No | No | No | 100 mm | 69.85 mm | 7 mm | -40 °C | 85 °C | 0.01 g | |
| Flexxon | INSPIRE | 2.5 Inch | 3D TLC | SATA III 6Gbps | 2000 GB | 520 MB/s | 565 MB/s | 5 V | 2000000 | 1500G/0.5ms | 80Hz ~ 2000Hz/20G | Yes | No | No | Yes | 100 mm | 69.85 mm | 7 mm | -40 °C | 85 °C | 0.01 g | |
| Flexxon | INSPIRE | 2.5 Inch | 3D TLC | SATA III 6Gbps | 2000 GB | 520 MB/s | 565 MB/s | 5 V | 2000000 | 1500G/0.5ms | 80Hz ~ 2000Hz/20G | Yes | No | No | No | 100 mm | 69.85 mm | 7 mm | – | 70 °C | 0.01 g | |
| Flexxon | INSPIRE | 2.5 Inch | 3D TLC | SATA III 6Gbps | 2000 GB | 520 MB/s | 565 MB/s | 5 V | 2000000 | 1500G/0.5ms | 80Hz ~ 2000Hz/20G | Yes | No | No | Yes | 100 mm | 69.85 mm | 7 mm | – | 70 °C | 0.01 g | |
| Flexxon | XTREME | 2.5 Inch | MLC | SATA III 6Gbps | 4 GB | 50 MB/s | 160 MB/s | 5 V | 2000000 | 1500G/0.5ms | 80Hz ~ 2000Hz/20G | Yes | No | No | No | 100 mm | 69.85 mm | 7 mm | -40 °C | 85 °C | 0.01 g | |
| Flexxon | XTREME | 2.5 Inch | MLC | SATA III 6Gbps | 4 GB | 50 MB/s | 160 MB/s | 5 V | 2000000 | 1500G/0.5ms | 80Hz ~ 2000Hz/20G | Yes | No | No | No | 100 mm | 69.85 mm | 7 mm | – | 70 °C | 0.01 g |
