LED Reflectors
LED reflectors for LEDs and modules from Ledil, Carclo, Fraen, Khatod, and Neumüller Elektronik. Available with asymmetrical, narrow, medium, wide, and ultra-wide beam characteristics. The reflectors enable targeted light distribution and are suitable for demanding applications in a wide range of lighting areas.
|
|
||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Carclo Optics | Reflector | 3535 | – | Ultra Wide | 79 ° | 1-fach | Reflector Silver | PC | – | 19.7 mm | 19.7 mm | 9.9 mm | – | – | 0.01 kg | |
| Carclo Optics | Reflector | 3030 | 3535 | – | Ultra Wide | 77 ° | 1-fach | Reflector | PC | – | 19.7 mm | 19.7 mm | 9.9 mm | – | – | 0.01 kg | |
| Carclo Optics | Reflector | 3535 | – | Ultra Wide | 55 ° | 1-fach | Reflector | PC | – | 19.7 mm | 19.7 mm | 11.8 mm | – | – | 0.01 kg | |
| Carclo Optics | Reflector | – | – | Wide | – | 4-fach | Reflector Silver | PC | – | 36.2 mm | 36.2 mm | 10.3 mm | – | – | 0.01 kg | |
| Carclo Optics | Reflector | 3030 | 5630 | – | Medium | 50 ° | 33-fach | Lens Clear | ABS | – | 268 mm | 64.6 mm | 13.1 mm | – | – | 0.04 kg | |
| Carclo Optics | Reflector | 3030 | 5630 | – | Medium | 50 ° | 33-fach | Lens Clear | ABS | – | 268 mm | 64.6 mm | 13.1 mm | – | – | 0.04 kg | |
| LEDiL Oy | Reflector | COB | 18.5 mm | – | 24 ° | 1-fach | Reflector Metal | Aluminum | – | 109.8 mm | 109.8 mm | 57.9 mm | -40 °C | 80 °C | 0.04 kg | |
| LEDiL Oy | Reflector | COB | 18.5 mm | – | 15 ° | 1-fach | Reflector Metal | Aluminum | – | 109.8 mm | 109.8 mm | 57.9 mm | -40 °C | 80 °C | 0.04 kg | |
| LEDiL Oy | Reflector | COB | 18.5 mm | – | 36 ° | 1-fach | Reflector Metal | Aluminum | – | 109.8 mm | 109.8 mm | 57.9 mm | -40 °C | 80 °C | 0.04 kg | |
| LEDiL Oy | Reflector | COB | 10 mm | Ultra Wide | 50 ° | 1-fach | Reflector Metal | Aluminum | – | 49.8 mm | 49.8 mm | 22.58 mm | -40 °C | 80 °C | 0.01 kg | |
| LEDiL Oy | Reflector | COB | 10 mm | Medium | 20 ° | 1-fach | Reflector Silver | Aluminum | – | 49.9 mm | 49.8 mm | 25 mm | -40 °C | 80 °C | 0.01 kg | |
| LEDiL Oy | Reflector | COB | 10 mm | Ultra Wide | 60 ° | 1-fach | Reflector Silver | Aluminum | – | 49.9 mm | 49.8 mm | 25 mm | -40 °C | 80 °C | 0.01 kg | |
| LEDiL Oy | Reflector | Zhaga Acrich COB | – | Narrow | 10 ° | 1-fach | Reflector Metal | PC | – | 119.5 mm | 119.5 mm | 74.5 mm | -40 °C | 90 °C | 0.01 kg | |
| LEDiL Oy | Reflector | COB | 29 mm | Narrow | 10 ° | 1-fach | Reflector Silver | PC | – | 119.5 mm | 119.5 mm | 74.3 mm | -40 °C | 90 °C | 0.04 kg | |
| LEDiL Oy | Reflector | COB | 29 mm | Narrow | 14 ° | 1-fach | Reflector Silver | PC | – | 119.5 mm | 119.5 mm | 74.5 mm | -40 °C | 90 °C | 0.04 kg | |
| LEDiL Oy | Reflector | COB | 29 mm | Medium | 51 ° | 1-fach | Reflector Metal | PC | – | 110 mm | 110 mm | 57.3 mm | -40 °C | 90 °C | 0.03 kg | |
| LEDiL Oy | Reflector | COB | 29 mm | Medium | 55 ° | 1-fach | Reflector Metal | PC | – | 110 mm | 110 mm | 57.3 mm | -40 °C | 90 °C | 0.01 kg | |
| LEDiL Oy | Reflector | COB | 29 mm | Medium | 55 ° | 1-fach | Reflector Metal | PC | – | 110 mm | 110 mm | 57.3 mm | -40 °C | 90 °C | 0.01 kg | |
| LEDiL Oy | Reflector | COB | 29 mm | Narrow | 13 ° | 1-fach | Reflector Metal | PC | – | 110 mm | 110 mm | 57.3 mm | -40 °C | 90 °C | 0.03 kg | |
| LEDiL Oy | Reflector | COB | 29 mm | Narrow | 14 ° | 1-fach | Reflector Metal | PC | – | 110 mm | 110 mm | 57.3 mm | -40 °C | 90 °C | 0.01 kg | |
| LEDiL Oy | Reflector | COB | 29 mm | Narrow | 14 ° | 1-fach | Reflector Metal | PC | – | 110 mm | 110 mm | 57.3 mm | -40 °C | 90 °C | 0.01 kg | |
| LEDiL Oy | Reflector | COB | 29 mm | Ultra Wide | 70 ° | 1-fach | Reflector Metal | PC | – | 110 mm | 110 mm | 57.3 mm | -40 °C | 90 °C | 0.03 kg | |
| LEDiL Oy | Reflector | COB | 29 mm | Ultra Wide | 70 ° | 1-fach | Reflector Metal | PC | – | 110 mm | 110 mm | 57.3 mm | -40 °C | 90 °C | 0.03 kg | |
| LEDiL Oy | Reflector | COB | 29 mm | Ultra Wide | 71 ° | 1-fach | Reflector Metal | PC | – | 110 mm | 110 mm | 57.3 mm | -40 °C | 90 °C | 0.01 kg | |
| LEDiL Oy | Reflector | COB | 29 mm | Ultra Wide | 71 ° | 1-fach | Reflector Metal | PC | – | 110 mm | 110 mm | 57.3 mm | -40 °C | 90 °C | 0.01 kg | |
| LEDiL Oy | Reflector | COB | 29 mm | Medium | 39 ° | 1-fach | Reflector Silver | PC | 2.2 mm | 81.95 mm | 81.95 mm | 31 mm | -40 °C | 90 °C | 0.01 kg | |
| LEDiL Oy | Reflector | Zhaga Acrich COB | – | Medium | 47 ° | 1-fach | Reflector Metal | PC | – | 82 mm | 82 mm | 31 mm | -40 °C | 90 °C | 0.01 kg | |
| LEDiL Oy | Reflector | COB | 39 mm | Narrow | 20° ° | 1-fach | Reflector Silver | PC | 2.2 mm | 82 mm | 82 mm | 31 mm | -40 °C | 90 °C | 0.01 kg | |
| LEDiL Oy | Reflector | COB | 39 mm | Wide | 50° ° | 1-fach | Reflector Silver | PC | 2.2 mm | 82 mm | 82 mm | 31 mm | -40 °C | 90 °C | 0.01 kg | |
| LEDiL Oy | Reflector | COB | 29 mm | Wide | 93 ° | 1-fach | Reflector White | PC | – | 81.95 mm | 81.95 mm | 31 mm | -40 °C | 90 °C | 0.01 kg | |
| LEDiL Oy | Reflector | COB | 29 mm | Wide | 93 ° | 1-fach | Reflector White | PC | 2.2 mm | 81.95 mm | 81.95 mm | 31 mm | -40 °C | 90 °C | 0.01 kg | |
| LEDiL Oy | Reflector | COB | 13 mm | Medium | 25 ° | 1-fach | Reflector Silver | PC | – | 70 mm | 70 mm | 41.9 mm | -40 °C | 90 °C | 0.01 kg | |
| LEDiL Oy | Reflector | COB | 13 mm | Narrow | 12 ° | 1-fach | Reflector Silver | PC | – | 70 mm | 70 mm | 41.9 mm | -40 °C | 90 °C | 0.01 kg | |
| LEDiL Oy | Reflector | COB | 13 mm | Wide | 40 ° | 1-fach | Reflector Silver | PC | – | 70 mm | 70 mm | 41.9 mm | -40 °C | 90 °C | 0.01 kg | |
| LEDiL Oy | Reflector | COB | 19 mm | Wide | 60 ° | 1-fach | Reflector Silver | PC | – | 70 mm | 70 mm | 41.9 mm | -40 °C | 90 °C | 0.01 kg | |
| LEDiL Oy | Reflector | COB | 19 mm | Wide | 60 ° | 1-fach | Reflector Silver | PC | 0.66 mm | 70 mm | 70 mm | 41.61 mm | -40 °C | 80 °C | 0.01 kg | |
| LEDiL Oy | Reflector | Y19 | – | Medium | 30 ° | 1-fach | Reflector Silver | PC | – | 22.2 mm | 22.2 mm | 14.3 mm | -40 °C | 90 °C | 0 kg | |
| LEDiL Oy | Reflector | COB | 8.6 mm | Narrow | 44 ° | 1-fach | Reflector Metal | PC | – | 22.6 mm | 22.6 mm | 12.8 mm | -40 °C | 90 °C | 0 kg | |
| LEDiL Oy | Reflector | COB | 18.4 mm | Medium | 30 ° | 1-fach | Reflector | PC | – | 45 mm | 45 mm | 18.95 mm | -40 °C | 90 °C | 0 kg | |
| LEDiL Oy | Reflector | COB | 18.4 mm | Narrow | 15 ° | 1-fach | Reflector | PC | – | 45 mm | 45 mm | 18.95 mm | -40 °C | 90 °C | 0 kg | |
| LEDiL Oy | Reflector | COB | 18.4 mm | Wide | 50 ° | 1-fach | Reflector | PC | – | 45 mm | 45 mm | 19.7 mm | -40 °C | 90 °C | 0 kg | |
| LEDiL Oy | Reflector | COB | 10 mm | Medium | 30 ° | 1-fach | Reflector Silver | PC | 1.3 mm | 45 mm | 45 mm | 20.1 mm | -40 °C | 90 °C | 0.01 kg | |
| LEDiL Oy | Reflector | COB | 10 mm | Narrow | 25 ° | 1-fach | Reflector Silver | PC | 1.3 mm | 45 mm | 45 mm | 20.1 mm | -40 °C | 90 °C | 0.01 kg | |
| LEDiL Oy | Reflector | V8 | – | Medium | 29 ° | 1-fach | Reflector Clear | PC | – | 29.6 mm | 29.6 mm | 17.2 mm | -40 °C | 90 °C | 0 kg | |
| LEDiL Oy | Reflector | V8 | – | Wide | 40.5 ° | 1-fach | Reflector Clear | PC | – | 29.6 mm | 29.6 mm | 17.2 mm | -40 °C | 90 °C | 0 kg | |
| LEDiL Oy | Reflector | COB | 8 mm | Wide | 55 ° | 1-fach | Reflector Clear | PC | – | 29.6 mm | 29.6 mm | 17.2 mm | -40 °C | 90 °C | 0 kg | |
| LEDiL Oy | Reflector | COB | 8 mm | Wide | 55 ° | 1-fach | Reflector Clear | PC | – | 32 mm | 32 mm | 20 mm | -40 °C | 90 °C | 0.01 kg | |
| FRAEN Corporation | Reflector | P5 II | – | Medium | 27 ° | 1-fach | Reflector Silver | PC | 0.93 mm | 34.8 mm | 34.8 mm | 17.5 mm | – | – | 0.01 kg |
