Lowpower LEDs
Low-power LEDs with a maximum forward current of 60 mA from renowned manufacturers. Available as 3 mm, 5 mm, and high-flux LEDs, as well as in color temperatures from 2700 K to 10000 K. Wavelengths from 460 nm to 635 nm are also available. Ideal for display, status, and decorative lighting applications with low power requirements.
|
|
||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Seoul Semiconductor | 803 | Cool White | – | 6500 K | 80 | 2064 mcd | 6 lm | 97 lm/W | 0.06 W | 3.1 V | 20 mA | 30 mA | 115 ° | No | 2 mm | 3 mm | 1.2 mm | -40 °C | 85 °C | SMD 803 | 0.01 kg | |
| Seoul Semiconductor | 803 | Cool White | – | 5600 K | 80 | 2064 mcd | 6 lm | 97 lm/W | 0.06 W | 3.1 V | 20 mA | 30 mA | 115 ° | No | 2 mm | 3 mm | 1.2 mm | -40 °C | 85 °C | SMD 803 | 0.01 kg | |
| Seoul Semiconductor | 803 | Cool White | – | 5000 K | 80 | 2064 mcd | 6 lm | 97 lm/W | 0.06 W | 3.1 V | 20 mA | 30 mA | 115 ° | No | 2 mm | 3 mm | 1.2 mm | -40 °C | 85 °C | SMD 803 | 0.01 kg | |
| Seoul Semiconductor | 803 | Natural White | – | 4500 K | 80 | 2064 mcd | 6 lm | 97 lm/W | 0.06 W | 3.1 V | 20 mA | 30 mA | 115 ° | No | 2 mm | 3 mm | 1.2 mm | -40 °C | 85 °C | SMD 803 | 0.01 kg | |
| Seoul Semiconductor | 803 | Natural White | – | 4000 K | 80 | 2064 mcd | 6 lm | 97 lm/W | 0.06 W | 3.1 V | 20 mA | 30 mA | 115 ° | No | 2 mm | 3 mm | 1.2 mm | -40 °C | 85 °C | SMD 803 | 0.01 kg | |
| Seoul Semiconductor | 803 | Warm White | – | 3500 K | 80 | 2064 mcd | 6 lm | 97 lm/W | 0.06 W | 3.1 V | 20 mA | 30 mA | 115 ° | No | 2 mm | 3 mm | 1.2 mm | -40 °C | 85 °C | SMD 803 | 0.01 kg | |
| Seoul Semiconductor | 803 | Warm White | – | 3000 K | 80 | 2064 mcd | 6 lm | 97 lm/W | 0.06 W | 3.1 V | 20 mA | 30 mA | 115 ° | No | 2 mm | 3 mm | 1.2 mm | -40 °C | 85 °C | SMD 803 | 0.01 kg | |
| Seoul Semiconductor | 803 | Warm White | – | 2700 K | 80 | 2064 mcd | 6 lm | 97 lm/W | 0.06 W | 3.1 V | 20 mA | 30 mA | 115 ° | No | 2 mm | 3 mm | 1.2 mm | -40 °C | 85 °C | SMD 803 | 0.01 kg | |
| Neumüller Elektronik | – | Red | 630 nm | – | – | 330 mcd | – | – | 0.04 W | 1.95 V | 20 mA | 30 mA | 20 ° | No | – | – | – | – | – | – | 0.01 kg | |
| Neumüller Elektronik | – | Orange | 605 nm | – | – | – | – | – | – | – | – | – | – | No | – | – | – | – | – | – | 0.01 kg | |
| Neumüller Elektronik | – | RGB | 632 | 518 | 468 nm | – | – | 65 mcd | – | – | – | – | 5 mA | – | 120 ° | No | 1 mm | 1 mm | 0.65 mm | – | – | – | 0.01 kg | |
| Neumüller Elektronik | – | Green | 572 nm | – | – | – | – | – | – | – | – | – | – | No | – | – | – | – | – | – | 0.01 kg | |
| Neumüller Elektronik | – | Red | 631 nm | – | – | – | – | – | – | – | – | – | – | No | – | – | – | – | – | – | 0.01 kg | |
| Neumüller Elektronik | – | – | – | – | – | 180 mcd | – | – | – | – | 5 mA | – | 130 ° | No | 1.6 mm | 0.8 mm | 0.55 mm | -20 °C | 80 °C | 1608 | 0.01 kg | |
| Neumüller Elektronik | 1706 | Red | 632 nm | – | – | 180 mcd | – | – | 0.04 W | 2 V | 20 mA | 60 mA | 130 ° | No | – | – | – | – | – | – | 0.01 kg | |
| Neumüller Elektronik | PLCC2 | Red | 622 nm | – | – | 20 mcd | – | – | 0.06 W | 2.2 V | 25 mA | 120 mA | 120 ° | No | – | – | – | – | – | – | 0.01 kg | |
| Neumüller Elektronik | PLCC2 | Green | 569 nm | – | – | 2 mcd | – | – | 0.05 W | 2.1 V | 25 mA | 120 mA | 120 ° | No | – | – | – | – | – | – | 0.01 kg | |
| Neumüller Elektronik | PLCC2 | Yellow | 587 nm | – | – | 1 mcd | – | – | 0.05 W | 2 V | 25 mA | 80 mA | 120 ° | No | – | – | – | – | – | – | 0.01 kg | |
| Neumüller Elektronik | 1608 | Yellow | 590 nm | – | – | 380 mcd | – | – | 0.07 W | 2.6 V | 25 mA | 90 mA | 130 ° | No | – | – | – | – | – | – | 0.01 kg | |
| Neumüller Elektronik | 1615 | RGB | 622 | 525 | 467 nm | – | – | 296 mcd | – | – | 0.06 W | 5 V | 12 mA | 25 mA | 120 ° | No | – | – | – | – | – | – | 0.01 kg | |
| Neumüller Elektronik | PLCC4 | RGB | 622 | 525 | 470 nm | – | – | 500 mcd | – | – | 0.06 W | 5 V | 12 mA | 20 mA | 120 ° | No | 3.48 mm | 3.68 mm | 1.95 mm | -40 °C | 85 °C | PLCC4 | 0.01 kg | |
| Neumüller Elektronik | 3210 | RGB | 622 | 525 | 470 nm | – | – | 360 mcd | – | – | 0.06 W | 5 V | 12 mA | 20 mA | 120 ° | No | 3.2 mm | 1 mm | 1.5 mm | -40 °C | 85 °C | – | 0.01 kg | |
| Neumüller Elektronik | PLCC4 | RGB | 622 | 522 | 466 nm | – | – | 1935 mcd | – | – | 0.06 W | 5 V | 12 mA | 20 mA | 120 ° | No | 3.48 mm | 3.68 mm | 1.95 mm | -40 °C | 85 °C | PLCC4 | 0.01 kg | |
| Neumüller Elektronik | 5050 | RGB | 622 | 525 | 468 nm | – | – | 320 mcd | – | – | 0.06 W | 5 V | 12 mA | – | 120 ° | No | 3.48 mm | 3.68 mm | 1.95 mm | -25 °C | 85 °C | 5050 | 0.01 kg | |
| Neumüller Elektronik | 603 | Red | 630 nm | – | – | 50 mcd | – | – | 0.04 W | 1.95 V | 20 mA | 75 mA | 130 ° | No | 1.6 mm | 0.8 mm | 0.4 mm | -40 °C | 85 °C | 603 | 0.01 kg | |
| Neumüller Elektronik | PLCC4 | Rot | 629 nm | – | – | 1662 mcd | – | – | – | 2.2 V | 50 mA | 125 mA | 15 ° | No | – | – | – | – | – | – | 0.01 kg | |
| Neumüller Elektronik | – | – | – | – | – | – | – | – | – | – | – | – | – | No | – | – | – | – | – | – | 0.01 kg | |
| Neumüller Elektronik | – | – | – | – | – | – | – | – | – | – | – | – | – | No | – | – | – | – | – | – | 0.01 kg | |
| Neumüller Elektronik | – | – | – | – | – | – | – | – | – | – | – | – | – | No | – | – | – | – | – | – | 0.01 kg | |
| Neumüller Elektronik | – | – | – | – | – | – | – | – | – | – | – | – | – | No | – | – | – | – | – | – | 0.01 kg | |
| Neumüller Elektronik | 4040 Side | Blue | 467 nm | – | – | 1085 mcd | – | – | 0.09 W | 2.9 V | 30 mA | 60 mA | 120 ° | No | – | – | – | – | – | – | 0.01 kg | |
| Neumüller Elektronik | 4040 Side | Pure Green | 522 nm | – | – | 3435 mcd | – | – | 0.09 W | 2.9 V | 30 mA | 60 mA | 120 ° | No | – | – | – | – | – | – | 0.01 kg | |
| Neumüller Elektronik | 4040 Side | Orange | 606 nm | – | – | 3235 mcd | – | – | 0.11 W | 2.2 V | 50 mA | 70 mA | 120 ° | No | – | – | – | – | – | – | 0.01 kg | |
| Neumüller Elektronik | 4040 Side | Red | 626 nm | – | – | 3235 mcd | – | – | 0.11 W | 2.2 V | 50 mA | 70 mA | 120 ° | No | – | – | – | – | – | – | 0.01 kg | |
| Neumüller Elektronik | – | Red | 634 nm | – | – | 2745 mcd | – | – | – | 2.27 V | 50 mA | 70 mA | 120 ° | No | – | – | – | – | – | – | 0.01 kg | |
| Neumüller Elektronik | – | RGB | – | – | – | – | – | – | – | – | – | – | – | No | – | – | – | – | – | – | 0.01 kg | |
| Neumüller Elektronik | – | RGB | 622 | 528 | 471 nm | – | – | – | – | – | – | – | 5 mA | – | 120 ° | No | – | – | – | – | – | – | 0.01 kg | |
| Neumüller Elektronik | – | RGB | – | – | – | – | – | – | – | – | – | – | – | No | – | – | – | – | – | – | 0.01 kg | |
| Neumüller Elektronik | – | Blue | – | – | – | – | – | – | – | – | – | – | – | No | – | – | – | – | – | – | 0.01 kg | |
| Neumüller Elektronik | – | Blue | – | – | – | – | – | – | – | – | – | – | – | No | – | – | – | – | – | – | 0.01 kg | |
| Neumüller Elektronik | – | RGB | – | – | – | – | – | – | – | – | – | – | – | No | – | – | – | – | – | – | 0.01 kg | |
| Neumüller Elektronik | – | True Green | 525 nm | – | – | – | – | – | – | – | – | – | – | No | – | – | – | – | – | – | 0.01 kg | |
| Neumüller Elektronik | – | Red | 630 nm | – | – | – | – | – | – | – | – | – | – | No | – | – | – | – | – | – | 0.01 kg | |
| Neumüller Elektronik | – | Red | 630 nm | – | – | – | – | – | – | – | – | – | – | No | – | – | – | – | – | – | 0.01 kg | |
| Neumüller Elektronik | – | Red | 630 nm | – | – | – | – | – | – | – | – | – | – | No | – | – | – | – | – | – | 0.01 kg | |
| Neumüller Elektronik | – | Green | 475 nm | – | – | – | – | – | – | – | – | – | – | No | 1.6 mm | 3.2 mm | 0.6 mm | – | – | – | 0.01 kg | |
| Neumüller Elektronik | 603 | True Green | 525 nm | – | – | 500 mcd | – | – | 0.04 W | 2.2 V | 20 mA | 100 mA | – | No | – | – | – | – | – | – | 0.01 kg | |
| Neumüller Elektronik | 1206 | Blau | 470 nm | – | – | 125 mcd | – | – | – | 3.2 V | 20 mA | 100 mA | 140 ° | No | 3.2 mm | 1.6 mm | 1.1 mm | -40 °C | 85 °C | 1206 | 0.01 kg |
