SD Cards

SD cards for industrial, medical and embedded applications in different capacities, NAND flash types, specifications and temperature ranges. They are suitable for data storage, logging and boot functions in compact systems. We support selection of robust SD cards for series applications with long-term availability.


FDMS001GME-1001 SD Card FxPro I MLC 1GB Diamond	Flexxon	FxPro I	SD	MLC	SD 3.0	1GB	10 MB/s	90 MB/s	2,7 - 3,6 V	3000000	1500G/0.5ms	80Hz ~ 2000Hz/20G	Yes	No	No	No	8	32 mm	24 mm	2.1 mm	-40 °C	85 °C	0.01 g
FDMS001GME-1006 SD Card FxPro I MLC 1GB Diamond (PLP)	Flexxon	FxPro I	SD	MLC	SD 3.0	1GB	10 MB/s	90 MB/s	2,7 - 3,6 V	3000000	1500G/0.5ms	80Hz ~ 2000Hz/20G	Yes	No	No	Yes	8	32 mm	24 mm	2.1 mm	-40 °C	85 °C	0.01 g
FDMS001GMG-1001 SD Card FxPro I MLC 1GB Gold	Flexxon	FxPro I	SD	MLC	SD 3.0	1GB	10 MB/s	90 MB/s	2,7 - 3,6 V	3000000	1500G/0.5ms	80Hz ~ 2000Hz/20G	Yes	No	No	No	8	32 mm	24 mm	2.1 mm	-25 °C	85 °C	0.01 g
FDMS001GMG-1006 SD Card FxPro I MLC 1GB Gold (PLP)	Flexxon	FxPro I	SD	MLC	SD 3.0	1GB	10 MB/s	90 MB/s	2,7 - 3,6 V	3000000	1500G/0.5ms	80Hz ~ 2000Hz/20G	Yes	No	No	Yes	8	32 mm	24 mm	2.1 mm	-25 °C	85 °C	0.01 g
FDMS001GSE-1001 SD Card FxPro I SLC 1GB Diamond	Flexxon	FxPro I	SD	SLC	SD 3.0	1GB	20 MB/s	20 MB/s	2,7 - 3,6 V	3000000	1500G/0.5ms	80Hz ~ 2000Hz/20G	Yes	No	No	No	8	32 mm	24 mm	2.1 mm	-40 °C	85 °C	0.01 g
FDMS001GSE-1004 SD Card FxPro I High IOPS SLC 1GB Diamond	Flexxon	FxPro I HighIOPS	SD	SLC	SD 5.1	1GB	15 MB/s	20 MB/s	2,7 - 3,6 V	3000000	1500G/0.5ms	80Hz ~ 2000Hz/20G	Yes	No	No	No	9	32 mm	24 mm	2.1 mm	-40 °C	85 °C	0.01 g
FDMS001GSG-1001 SD Card FxPro I SLC 1GB Gold	Flexxon	FxPro I	SD	SLC	SD 3.0	1GB	20 MB/s	20 MB/s	2,7 - 3,6 V	3000000	1500G/0.5ms	80Hz ~ 2000Hz/20G	Yes	No	No	No	8	32 mm	24 mm	2.1 mm	-25 °C	85 °C	0.01 g
FDMS001GSG-1004 SD Card FxPro I High IOPS SLC 1GB Gold	Flexxon	FxPro I HighIOPS	SD	SLC	SD 5.1	1GB	15 MB/s	20 MB/s	2,7 - 3,6 V	3000000	1500G/0.5ms	80Hz ~ 2000Hz/20G	Yes	No	No	No	9	32 mm	24 mm	2.1 mm	-25 °C	85 °C	0.01 g
FDMS001TEC-T300 SD Card FxMav QLC 1TB	Flexxon	FxMav	SD	QLC	SD 6.1	1TB	95 MB/s	100 MB/s	2,7 - 3,6 V	2000000	1500G/0.5ms	80Hz ~ 2000Hz/20G	No	No	No	No	8	32 mm	24 mm	2.1 mm	-25 °C	85 °C	0.01 g
FDMS002GME-1001 SD Card FxPro I MLC 2GB Diamond	Flexxon	FxPro I	SD	MLC	SD 3.0	2GB	10 MB/s	90 MB/s	2,7 - 3,6 V	3000000	1500G/0.5ms	80Hz ~ 2000Hz/20G	Yes	No	No	No	8	32 mm	24 mm	2.1 mm	-40 °C	85 °C	0.01 g
FDMS002GME-1006 SD Card FxPro I MLC 2GB Diamond (PLP)	Flexxon	FxPro I	SD	MLC	SD 3.0	2GB	10 MB/s	90 MB/s	2,7 - 3,6 V	3000000	1500G/0.5ms	80Hz ~ 2000Hz/20G	Yes	No	No	Yes	8	32 mm	24 mm	2.1 mm	-40 °C	85 °C	0.01 g
FDMS002GMG-1001 SD Card FxPro I MLC 2GB Gold	Flexxon	FxPro I	SD	MLC	SD 3.0	2GB	10 MB/s	90 MB/s	2,7 - 3,6 V	3000000	1500G/0.5ms	80Hz ~ 2000Hz/20G	Yes	No	No	No	8	32 mm	24 mm	2.1 mm	-25 °C	85 °C	0.01 g
FDMS002GMG-1006 SD Card FxPro I MLC 2GB Gold (PLP)	Flexxon	FxPro I	SD	MLC	SD 3.0	2GB	10 MB/s	90 MB/s	2,7 - 3,6 V	3000000	1500G/0.5ms	80Hz ~ 2000Hz/20G	Yes	No	No	Yes	8	32 mm	24 mm	2.1 mm	-25 °C	85 °C	0.01 g
FDMS002GPE-1001 SD Card FxPro I pSLC 2GB Diamond	Flexxon	FxPro I	SD	pSLC	SD 3.0	2GB	20 MB/s	20 MB/s	2,7 - 3,6 V	3000000	1500G/0.5ms	80Hz ~ 2000Hz/20G	Yes	No	No	No	8	32 mm	24 mm	2.1 mm	-40 °C	85 °C	0.01 g
FDMS002GPE-1004 SD Card FxPro I High IOPS pSLC 2GB Diamond	Flexxon	FxPro I HighIOPS	SD	pSLC	SD 5.1	2GB	20 MB/s	20 MB/s	2,7 - 3,6 V	3000000	1500G/0.5ms	80Hz ~ 2000Hz/20G	Yes	No	No	No	9	32 mm	24 mm	2.1 mm	-40 °C	85 °C	0.01 g
FDMS002GPG-1001 SD Card FxPro I pSLC 2GB Gold	Flexxon	FxPro I	SD	pSLC	SD 3.0	2GB	20 MB/s	20 MB/s	2,7 - 3,6 V	3000000	1500G/0.5ms	80Hz ~ 2000Hz/20G	Yes	No	No	No	8	32 mm	24 mm	2.1 mm	-25 °C	85 °C	0.01 g
FDMS002GPG-1004 SD Card FxPro I High IOPS pSLC 2GB Gold	Flexxon	FxPro I HighIOPS	SD	pSLC	SD 5.1	2GB	20 MB/s	20 MB/s	2,7 - 3,6 V	3000000	1500G/0.5ms	80Hz ~ 2000Hz/20G	Yes	No	No	No	9	32 mm	24 mm	2.1 mm	-25 °C	85 °C	0.01 g
FDMS002GSE-1001 SD Card FxPro I SLC 2GB Diamond	Flexxon	FxPro I	SD	SLC	SD 3.0	2GB	20 MB/s	20 MB/s	2,7 - 3,6 V	3000000	1500G/0.5ms	80Hz ~ 2000Hz/20G	Yes	No	No	No	8	32 mm	24 mm	2.1 mm	-40 °C	85 °C	0.01 g
FDMS002GSE-1004 SD Card FxPro I High IOPS SLC 2GB Diamond	Flexxon	FxPro I HighIOPS	SD	SLC	SD 5.1	2GB	15 MB/s	20 MB/s	2,7 - 3,6 V	3000000	1500G/0.5ms	80Hz ~ 2000Hz/20G	Yes	No	No	No	9	32 mm	24 mm	2.1 mm	-40 °C	85 °C	0.01 g
FDMS002GSG-1001 SD Card FxPro I SLC 2GB Gold	Flexxon	FxPro I	SD	SLC	SD 3.0	2GB	20 MB/s	20 MB/s	2,7 - 3,6 V	3000000	1500G/0.5ms	80Hz ~ 2000Hz/20G	Yes	No	No	No	8	32 mm	24 mm	2.1 mm	-25 °C	85 °C	0.01 g
FDMS002GSG-1004 SD Card FxPro I High IOPS SLC 2GB Gold	Flexxon	FxPro I HighIOPS	SD	SLC	SD 5.1	2GB	15 MB/s	20 MB/s	2,7 - 3,6 V	3000000	1500G/0.5ms	80Hz ~ 2000Hz/20G	Yes	No	No	No	9	32 mm	24 mm	2.1 mm	-25 °C	85 °C	0.01 g
FDMS004GCE-3201 SD Card FxAdv II 3D-NAND pSLC 4GB Diamond	Flexxon	FxAdv II	SD	3D pSLC	SD 6.1	4GB	85 MB/s	95 MB/s	2,7 - 3,6 V	3000000	1500G/0.5ms	80Hz ~ 2000Hz/20G	Yes	No	Yes	No	9	32 mm	24 mm	2.1 mm	-40 °C	85 °C	0.01 g
FDMS004GCG-3101 SD Card FxAdv 3D-NAND pSLC 4GB Gold	Flexxon	FxAdv	SD	3D pSLC	SD 6.1	4GB	65 MB/s	95 MB/s	2,7 - 3,6 V	3000000	1500G/0.5ms	80Hz ~ 2000Hz/20G	Yes	Yes	No	No	9	32 mm	24 mm	2.1 mm	-25 °C	85 °C	0.01 g
FDMS004GCG-3201 SD Card FxAdv II 3D-NAND pSLC 4GB Gold	Flexxon	FxAdv II	SD	3D pSLC	SD 6.1	4GB	85 MB/s	95 MB/s	2,7 - 3,6 V	3000000	1500G/0.5ms	80Hz ~ 2000Hz/20G	Yes	No	Yes	No	9	32 mm	24 mm	2.1 mm	-25 °C	85 °C	0.01 g
FDMS004GME-1001 SD Card FxPro I MLC 4GB Diamond	Flexxon	FxPro I	SD	MLC	SD 3.0	4GB	10 MB/s	90 MB/s	2,7 - 3,6 V	3000000	1500G/0.5ms	80Hz ~ 2000Hz/20G	Yes	No	No	No	8	32 mm	24 mm	2.1 mm	-40 °C	85 °C	0.01 g
FDMS004GME-1004 SD Card FxPro I High IOPS MLC 4GB Diamond	Flexxon	FxPro I HighIOPS	SD	MLC	SD 5.1	4GB	10 MB/s	80 MB/s	2,7 - 3,6 V	3000000	1500G/0.5ms	80Hz ~ 2000Hz/20G	Yes	No	No	No	9	32 mm	24 mm	2.1 mm	-40 °C	85 °C	0.01 g
FDMS004GME-1006 SD Card FxPro I MLC 4GB Diamond (PLP)	Flexxon	FxPro I	SD	MLC	SD 3.0	4GB	10 MB/s	90 MB/s	2,7 - 3,6 V	3000000	1500G/0.5ms	80Hz ~ 2000Hz/20G	Yes	No	No	Yes	8	32 mm	24 mm	2.1 mm	-40 °C	85 °C	0.01 g
FDMS004GME-1007 SD Card FxPro I High IOPS MLC 4GB Gold (PLP)	Flexxon	FxPro I HighIOPS	SD	MLC	SD 5.1	4GB	10 MB/s	80 MB/s	2,7 - 3,6 V	3000000	1500G/0.5ms	80Hz ~ 2000Hz/20G	Yes	No	No	Yes	9	32 mm	24 mm	2.1 mm	-25 °C	85 °C	0.01 g
FDMS004GME-B400 SD Card FxStd MLC 4GB	Flexxon	FxStd	SD	MLC	SD 3.0	4GB	25 MB/s	70 MB/s	2,7 - 3,6 V	2000000	1500G/0.5ms	80Hz ~ 2000Hz/20G	Yes	No	No	No	9	32 mm	24 mm	2.1 mm	-40 °C	85 °C	0.01 g
FDMS004GME-XE00 WORM SD Card MLC 4GB Diamond	Flexxon	WORM	SD	MLC	SD 6.1	4GB	15 MB/s	72 MB/s	2,7 - 3,6 V	3000000	1500G/0.5ms	80Hz ~ 2000Hz/20G	Yes	Yes	No	No	–	32 mm	24 mm	2.1 mm	-40 °C	85 °C	0.01 g
FDMS004GME-XS00 X-Mask SD Card MLC 4GB Diamond	Flexxon	X-Mask	SD	MLC	SD 3.0	4GB	25 MB/s	90 MB/s	2,7 - 3,6 V	3000000	1500G/0.5ms	80Hz ~ 2000Hz/20G	Yes	No	No	No	–	32 mm	24 mm	2.1 mm	-40 °C	85 °C	0.01 g
FDMS004GMG-1001 SD Card FxPro I MLC 4GB Gold	Flexxon	FxPro I	SD	MLC	SD 3.0	4GB	10 MB/s	90 MB/s	2,7 - 3,6 V	3000000	1500G/0.5ms	80Hz ~ 2000Hz/20G	Yes	No	No	No	8	32 mm	24 mm	2.1 mm	-25 °C	85 °C	0.01 g
FDMS004GMG-1004 SD Card FxPro I High IOPS MLC 4GB Gold	Flexxon	FxPro I HighIOPS	SD	MLC	SD 5.1	4GB	10 MB/s	80 MB/s	2,7 - 3,6 V	3000000	1500G/0.5ms	80Hz ~ 2000Hz/20G	Yes	No	No	No	9	32 mm	24 mm	2.1 mm	-25 °C	85 °C	0.01 g
FDMS004GMG-1006 SD Card FxPro I MLC 4GB Gold (PLP)	Flexxon	FxPro I	SD	MLC	SD 3.0	4GB	10 MB/s	90 MB/s	2,7 - 3,6 V	3000000	1500G/0.5ms	80Hz ~ 2000Hz/20G	Yes	No	No	Yes	8	32 mm	24 mm	2.1 mm	-25 °C	85 °C	0.01 g
FDMS004GMG-1007 SD Card FxPro I High IOPS MLC 4GB Diamond (PLP)	Flexxon	FxPro I HighIOPS	SD	MLC	SD 5.1	4GB	10 MB/s	80 MB/s	2,7 - 3,6 V	3000000	1500G/0.5ms	80Hz ~ 2000Hz/20G	Yes	No	No	Yes	9	32 mm	24 mm	2.1 mm	-40 °C	85 °C	0.01 g
FDMS004GMG-XE00 WORM SD Card MLC 4GB Gold	Flexxon	WORM	SD	MLC	SD 6.1	4GB	15 MB/s	72 MB/s	2,7 - 3,6 V	3000000	1500G/0.5ms	80Hz ~ 2000Hz/20G	Yes	Yes	No	No	–	32 mm	24 mm	2.1 mm	-25 °C	85 °C	0.01 g
FDMS004GMG-XS00 X-Mask SD Card MLC 4GB Gold	Flexxon	X-Mask	SD	MLC	SD 3.0	4GB	25 MB/s	90 MB/s	2,7 - 3,6 V	3000000	1500G/0.5ms	80Hz ~ 2000Hz/20G	Yes	No	No	No	–	32 mm	24 mm	2.1 mm	-25 °C	85 °C	0.01 g
FDMS004GPE-1001 SD Card FxPro I pSLC 4GB Diamond	Flexxon	FxPro I	SD	pSLC	SD 3.0	4GB	45 MB/s	90 MB/s	2,7 - 3,6 V	3000000	1500G/0.5ms	80Hz ~ 2000Hz/20G	Yes	No	No	No	8	32 mm	24 mm	2.1 mm	-40 °C	85 °C	0.01 g
FDMS004GPE-1004 SD Card FxPro I High IOPS pSLC 4GB Diamond	Flexxon	FxPro I HighIOPS	SD	pSLC	SD 5.1	4GB	80 MB/s	90 MB/s	2,7 - 3,6 V	3000000	1500G/0.5ms	80Hz ~ 2000Hz/20G	Yes	No	No	No	9	32 mm	24 mm	2.1 mm	-40 °C	85 °C	0.01 g
FDMS004GPE-B400 SD Card FxStd pSLC 4GB	Flexxon	FxStd	SD	pSLC	SD 3.0	4GB	55 MB/s	80 MB/s	2,7 - 3,6 V	2000000	1500G/0.5ms	80Hz ~ 2000Hz/20G	Yes	No	No	No	9	32 mm	24 mm	2.1 mm	-40 °C	85 °C	0.01 g
FDMS004GPE-N200 SD Card FxPrem II pSLC 4GB Diamond	Flexxon	FxPrem II	SD	pSLC	SD 3.0	4GB	50 MB/s	95 MB/s	2,7 - 3,6 V	3000000	1500G/0.5ms	80Hz ~ 2000Hz/20G	Yes	Yes	No	No	9	32 mm	24 mm	2.1 mm	-40 °C	85 °C	0.01 g
FDMS004GPG-1001 SD Card FxPro I pSLC 4GB Gold	Flexxon	FxPro I	SD	pSLC	SD 3.0	4GB	45 MB/s	90 MB/s	2,7 - 3,6 V	3000000	1500G/0.5ms	80Hz ~ 2000Hz/20G	Yes	No	No	No	8	32 mm	24 mm	2.1 mm	-25 °C	85 °C	0.01 g
FDMS004GPG-1004 SD Card FxPro I High IOPS pSLC 4GB Gold	Flexxon	FxPro I HighIOPS	SD	pSLC	SD 5.1	4GB	80 MB/s	90 MB/s	2,7 - 3,6 V	3000000	1500G/0.5ms	80Hz ~ 2000Hz/20G	Yes	No	No	No	9	32 mm	24 mm	2.1 mm	-25 °C	85 °C	0.01 g
FDMS004GPG-N200 SD Card FxPrem II pSLC 4GB Gold	Flexxon	FxPrem II	SD	pSLC	SD 3.0	4GB	50 MB/s	95 MB/s	2,7 - 3,6 V	3000000	1500G/0.5ms	80Hz ~ 2000Hz/20G	Yes	Yes	No	No	9	32 mm	24 mm	2.1 mm	-25 °C	85 °C	0.01 g
FDMS004GSE-1001 SD Card FxPro I SLC 4GB Diamond	Flexxon	FxPro I	SD	SLC	SD 3.0	4GB	35 MB/s	35 MB/s	2,7 - 3,6 V	3000000	1500G/0.5ms	80Hz ~ 2000Hz/20G	Yes	No	No	No	8	32 mm	24 mm	2.1 mm	-40 °C	85 °C	0.01 g
FDMS004GSE-1004 SD Card FxPro I High IOPS SLC 4GB Diamond	Flexxon	FxPro I HighIOPS	SD	SLC	SD 5.1	4GB	30 MB/s	70 MB/s	2,7 - 3,6 V	3000000	1500G/0.5ms	80Hz ~ 2000Hz/20G	Yes	No	No	No	9	32 mm	24 mm	2.1 mm	-40 °C	85 °C	0.01 g
FDMS004GSE-N200 SD Card FxPrem II SLC 4GB Diamond	Flexxon	FxPrem II	SD	SLC	SD 3.0	4GB	30 MB/s	80 MB/s	2,7 - 3,6 V	3000000	1500G/0.5ms	80Hz ~ 2000Hz/20G	Yes	Yes	No	No	9	32 mm	24 mm	2.1 mm	-40 °C	85 °C	0.01 g
FDMS004GSG-1001 SD Card FxPro I SLC 4GB Gold	Flexxon	FxPro I	SD	SLC	SD 3.0	4GB	35 MB/s	35 MB/s	2,7 - 3,6 V	3000000	1500G/0.5ms	80Hz ~ 2000Hz/20G	Yes	No	No	No	8	32 mm	24 mm	2.1 mm	-25 °C	85 °C	0.01 g
