Multicolor LEDs
Multicolor LEDs enable dynamic lighting solutions with limited installation space and energy requirements. In addition to classic RGB LEDs, we offer multicolor LEDs with multiple chips in one package, e.g., RGBW or tunable. Suitable for color mixing, status indicators, and accent lighting—with defined electrical characteristics, dimmable, and easy to control.
|
|
|||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Bivar | 1.8MM | Hyper Red | Green | 640 | 568 nm | – | 4 | 4 mcd | – | – | 0.04 W | 2 V | 20 mA | – | 70 ° | No | – | – | – | – | – | 1.8mm | – | |
| Bivar | 1.8MM | Yellow | Green | 590 | 568 nm | – | 3,5 | 4,5 mcd | – | – | 0.04 W | 2 V | 20 mA | – | 50 ° | No | – | – | – | – | – | 1.8mm | – | |
| Bivar | 3MM (T-1) | Red | Green | 625 | 568 nm | – | 6 | 6 mcd | – | – | 0.04 W | 2 V | 20 mA | – | 45 ° | No | – | – | – | – | – | 3mm (T-1) | – | |
| Bivar | 3MM (T-1) | Red | Green | 625 | 568 nm | – | 6 | 6 mcd | – | – | 0,04 | 0,042 W | 2,0 | 2,1 V | 20 mA | – | 45 ° | No | – | – | – | – | – | 3mm (T-1) | – | |
| Bivar | 3MM (T-1) | Red | Green | 625 | 568 nm | – | 30 | 30 mcd | – | – | 0,04 | 0,042 W | 2,0 | 2,1 V | 20 mA | – | 40 ° | No | – | – | – | – | – | 3mm (T-1) | – | |
| Bivar | 3MM (T-1) | Red | Yellow | 625 | 590 nm | – | 30 | 20 mcd | – | – | 0.04 W | 2 V | 20 mA | – | 40 ° | No | – | – | – | – | – | 3mm (T-1) | – | |
| Bivar | 3MM (T-1) | Yellow | Green | 590 | 568 nm | – | 4 | 6 mcd | – | – | 0,04 | 0,042 W | 2,0 | 2,1 V | 20 mA | – | 45 ° | No | – | – | – | – | – | 3mm (T-1) | – | |
| Bivar | 3MM (T-1) | Yellow | Green | 590 | 568 nm | – | 20 | 30 mcd | – | – | 0.04 W | 2 V | 20 mA | – | 40 ° | No | – | – | – | – | – | 3mm (T-1) | – | |
| Bivar | 3MM (T-1) | Red | Green | 625 | 568 nm | – | 6 | 6 mcd | – | – | 0.04 W | 2 V | 20 mA | – | 45 ° | No | – | – | – | – | – | 3mm (T-1) | – | |
| Bivar | 3MM (T-1) | Yellow | Green | 590 | 568 nm | – | 4 | 6 mcd | – | – | 0,04 | 0,042 W | 2,0 | 2,1 V | 20 mA | – | 45 ° | No | – | – | – | – | – | 3mm (T-1) | – | |
| Bivar | 3MM (T-1) | Yellow | Green | 590 | 568 nm | – | 4 | 6 mcd | – | – | 0,04 | 0,042 W | 2,0 | 2,1 V | 20 mA | – | 45 ° | No | – | – | – | – | – | 3mm (T-1) | – | |
| Bivar | 3MM (T-1) | Red | Green | 625 | 568 nm | – | 8 | 8 mcd | – | – | 0,06 | 0,063 W | 2,0 | 2,1 V | 30 mA | – | 40 ° | No | – | – | – | – | – | 3mm (T-1) | – | |
| Bivar | 3MM (T-1) | Hyper Red | Green | 645 | 568 nm | – | 12 | 8 mcd | – | – | 0,034 | 0,042 W | 1,7 | 2,1 V | 20 mA | – | 45 ° | No | – | – | – | – | – | 3mm (T-1) | – | |
| Bivar | 3MM (T-1) | Hyper Red | Green | 660 | 568 nm | – | 120 | 50 mcd | – | – | 0,034 | 0,042 W | 1,7 | 2,1 V | 20 mA | – | 40 ° | No | – | – | – | – | – | 3mm (T-1) | – | |
| Bivar | 3MM (T-1) | Hyper Red | Green | 645 | 568 nm | – | 100 | 60 mcd | – | – | 0,034 | 0,042 W | 1,7 | 2,1 V | 20 mA | – | 20 ° | No | – | – | – | – | – | 3mm (T-1) | – | |
| Bivar | 5MM (T-1 3/4) | Red | Green | 625 | 568 nm | – | 6 | 8 mcd | – | – | 0,04 | 0,042 W | 2,0 | 2,1 V | 20 mA | – | 45 ° | No | – | – | – | – | – | 5mm (T-1 3/4) | – | |
| Bivar | 5MM (T-1 3/4) | Red | Green | 625 | 568 nm | – | 35 | 35 mcd | – | – | 0,04 | 0,042 W | 2,0 | 2,1 V | 20 mA | – | 40 ° | No | – | – | – | – | – | 5mm (T-1 3/4) | – | |
| Bivar | 5MM (T-1 3/4) | Red | Green | 625 | 568 nm | – | 4 | 6 mcd | – | – | 0,04 | 0,042 W | 2,0 | 2,1 V | 20 mA | – | 40 ° | No | – | – | – | – | – | 5mm (T-1 3/4) | – | |
| Bivar | 5MM (T-1 3/4) | Red | Green | 625 | 568 nm | – | 4 | 6 mcd | – | – | 0,04 | 0,042 W | 2,0 | 2,1 V | 20 mA | – | 40 ° | No | – | – | – | – | – | 5mm (T-1 3/4) | – | |
| Bivar | 5MM (T-1 3/4) | Red | Green | 625 | 568 nm | – | 35 | 35 mcd | – | – | 0,04 | 0,042 W | 2,0 | 2,1 V | 20 mA | – | 40 ° | No | – | – | – | – | – | 5mm (T-1 3/4) | – | |
| Bivar | 5MM (T-1 3/4) | Yellow | Green | 590 | 568 nm | – | 30 | 35 mcd | – | – | 0,04 | 0,042 W | 2,0 | 2,1 V | 20 mA | – | 40 ° | No | – | – | – | – | – | 5mm (T-1 3/4) | – | |
| Bivar | 5MM (T-1 3/4) | Yellow | Green | 590 | 568 nm | – | 4 | 6 mcd | – | – | 0,04 | 0,042 W | 2,0 | 2,1 V | 20 mA | – | 40 ° | No | – | – | – | – | – | 5mm (T-1 3/4) | – | |
| Bivar | 5MM (T-1 3/4) | Yellow | Green | 590 | 568 nm | – | 30 | 35 mcd | – | – | 0,04 | 0,042 W | 2,0 | 2,1 V | 20 mA | – | 40 ° | No | – | – | – | – | – | 5mm (T-1 3/4) | – | |
| Bivar | 5MM (T-1 3/4) | Red | Green | 625 | 568 nm | – | 8 | 8 mcd | – | – | 0,04 | 0,042 W | 2,0 | 2,1 V | 20 mA | – | 45 ° | No | – | – | – | – | – | 5mm (T-1 3/4) | – | |
| Bivar | 5MM (T-1 3/4) | Yellow | Green | 590 | 568 nm | – | 6 | 8 mcd | – | – | 0,04 | 0,042 W | 2,0 | 2,1 V | 20 mA | – | 45 ° | No | – | – | – | – | – | 5mm (T-1 3/4) | – | |
| Neumüller Elektronik | – | RGB | 632 | 518 | 468 nm | – | 65 mcd | – | – | – | – | 5 mA | – | 120 ° | No | 1 mm | 1 mm | 0.65 mm | – | – | – | 0.01 kg | |
| Neumüller Elektronik | 1615 | RGB | 622 | 525 | 467 nm | – | 296 mcd | – | – | 0.06 W | 5 V | 12 mA | 25 mA | 120 ° | No | – | – | – | – | – | – | 0.01 kg | |
| Neumüller Elektronik | PLCC4 | RGB | 622 | 525 | 470 nm | – | 500 mcd | – | – | 0.06 W | 5 V | 12 mA | 20 mA | 120 ° | No | 3.48 mm | 3.68 mm | 1.95 mm | -40 °C | 85 °C | PLCC4 | 0.01 kg | |
| Neumüller Elektronik | 3210 | RGB | 622 | 525 | 470 nm | – | 360 mcd | – | – | 0.06 W | 5 V | 12 mA | 20 mA | 120 ° | No | 3.2 mm | 1 mm | 1.5 mm | -40 °C | 85 °C | – | 0.01 kg | |
| Neumüller Elektronik | PLCC4 | RGB | 622 | 522 | 466 nm | – | 1935 mcd | – | – | 0.06 W | 5 V | 12 mA | 20 mA | 120 ° | No | 3.48 mm | 3.68 mm | 1.95 mm | -40 °C | 85 °C | PLCC4 | 0.01 kg | |
| Neumüller Elektronik | 5050 | RGB | 622 | 525 | 468 nm | – | 320 mcd | – | – | 0.06 W | 5 V | 12 mA | – | 120 ° | No | 3.48 mm | 3.68 mm | 1.95 mm | -25 °C | 85 °C | 5050 | 0.01 kg | |
| Neumüller Elektronik | – | RGB | – | – | – | – | – | – | – | – | – | – | No | – | – | – | – | – | – | 0.01 kg | |
| Neumüller Elektronik | – | RGB | – | – | – | – | – | – | – | – | – | – | No | – | – | – | – | – | – | 0.01 kg | |
| Neumüller Elektronik | – | RGB | – | – | – | – | – | – | – | – | – | – | No | – | – | – | – | – | – | 0.01 kg | |
| Neumüller Elektronik | 2835 | Rot | 633 nm | – | – | 7 lm | – | – | 2 V | 60 mA | 60 mA | 120 ° | No | 1.6 mm | 0.8 mm | 0.5 mm | -40 °C | 85 °C | – | 0.01 kg | |
| Neumüller Elektronik | PLCC4 | RGB | 622 | 520 | 467 nm | – | 800 | 1400 | 320 mcd | – | – | 0.1 W | 5 V | 20 mA | 25 mA | 120 ° | No | 3.5 mm | 3.5 mm | 1.9 mm | -40 °C | 85 °C | PLCC4 | 0.01 kg | |
| Neumüller Elektronik | 5050 | RGBW | 622 | 525 | 468 nm | – | 320 mcd | – | – | 0.06 W | 5 V | 12 mA | – | 120 ° | No | 5 mm | 5 mm | 1 mm | -25 °C | 85 °C | 5050 | 0.01 kg | |
| Neumüller Elektronik | 5050 | RGBW | 622 | 525 | 468 nm | – | 320 mcd | – | – | 0.06 W | 5 V | 12 mA | – | 120 ° | No | 5 mm | 5 mm | 1 mm | -25 °C | 85 °C | 5050 | 0.01 kg | |
| OPTEK Technology | 3228 | RGB | – | – | – | – | – | – | – | – | – | 120 ° | No | 12.6 mm | 11 mm | 0.75 mm | -40 °C | 100 °C | – | 0.01 kg | |
| OPTEK Technology | – | RGB | – | – | – | – | – | – | – | – | – | 150 ° | No | 12 mm | 0.4 mm | – | -40 °C | 85 °C | – | 0.01 kg | |
| OPTEK Technology | – | RGB | – | – | – | – | – | – | – | – | – | 150 ° | No | 12.6 mm | 0.4 mm | – | -40 °C | 85 °C | – | 0.01 kg | |
| OPTEK Technology | – | RGB | – | – | – | – | – | – | – | – | – | 120 ° | No | 22.4 mm | 23.6 mm | 9.81 mm | -40 °C | 100 °C | – | 0.01 kg | |
| Bivar | Rectangular | Red | Green | 625 | 568 nm | – | 3 | 2,5 mcd | – | – | 0,04 | 0,042 W | 2,0 | 2,1 V | 20 mA | – | 120 ° | No | – | – | – | – | – | 2mm x 3mm | – | |
| Bivar | 7.6MM Square (Piranha) | Blue | True Green | 460 | 515 nm | – | 3000 | 10000 mcd | – | – | 0.19 W | 3.8 V | 50 mA | – | 45 ° | No | – | – | – | – | – | 7.6mm x 7.6mm | – | |
| Bivar | 7.6MM Square (Piranha) | Blue | True Green | 460 | 515 nm | – | 1000 | 2000 mcd | – | – | 0.19 W | 3.8 V | 50 mA | – | 80 ° | No | – | – | – | – | – | 7.6mm x 7.6mm | – | |
| Bivar | 7.6MM Square (Piranha) | Blue | True Green | 460 | 515 nm | – | 250 | 1000 mcd | – | – | 0.19 W | 3.8 V | 50 mA | – | 160 ° | No | – | – | – | – | – | 7.6mm x 7.6mm | – | |
| Bivar | 7.6MM Square (Piranha) | Amber | Blue | 617 | 460 nm | – | 4000 | 3000 mcd | – | – | 0.19 W | 3.8 V | 50 mA | – | 45 ° | No | – | – | – | – | – | 7.6mm x 7.6mm | – | |
| Bivar | 7.6MM Square (Piranha) | Amber | Blue | 617 | 460 nm | – | 3000 | 3000 mcd | – | – | 0.19 W | 3.8 V | 50 mA | – | 80 ° | No | – | – | – | – | – | 7.6mm x 7.6mm | – |
