Peltier Module | 223,7 W | 16,7 V
The PowerCycling PCX24-128-F2-5555-TA-RT-W6 peltier module uses next-generation thermoelectric materials and an improved design to provide applications with a high-performance and longer-lasting thermoelectric cooler module. Without sacrificing performance, the PCX peltier thermoelectric module is qualified to withstand harsh thermal cycle testing under the latest PCR qualification standards. The thermoelectric module has a cooling capacity of 223,7 W.Features: - High thermal cycling capability - Precise temperature control - Solid-state operation - Boosted performance with next-gen material Laird Part Number: 387005669 |
|
Manufacturer: | Laird Thermal Systems | |
Productgroup: | Peltier Modules | |
Part Number: | PCX24-128-F2-5555-TA-RT-W6 | |
Series: | PowerCycling PCX | |
Datasheet: | Open datasheet | |
State: | 🟢 Active |
Note article Request article |
Qc Max : | 223.7 W | ||
ΔT Max : | 82.6 °C | ||
I Max : | 23.4 A | ||
V Max : | 16.7 V | ||
AC Resistance : | 0.63 Ω | ||
Stages: | 1 | ||
Finishing: | Lapped | ||
Sealing: | RTV | ||
Length: | 59 mm | ||
Width: | 55 mm | ||
Heigth: | 4 mm | ||
Min. operating temperature: | -10 °C | ||
Max. operating temperature: | 120 °C |
|
Hint: current revision of the supplier datasheet is applicable
