NVMe SSDs

Wide range of NVMe SSDs with strong performance and interoperability for client and enterprise application. Our NVMe PCIe 3.0 and NVMe PCIe 4.0 SSDs are available in various form factors, such as M.2, U.2, and HHHL, as well as different capacities. SSDs with an operating temperature range of -40C° to +85C° are also available for industrial applications.

	Product	Manufacturer	Series	Form Factor	Memory Type	Interface	Capacity	Write Performance	Read Performance	Operating Voltage	MTBF	Shock Resistance	Vibration Resistance	Industrie	Medical	Military	Power Loss Protection	Length	Width	Heigth	Min. operating temperature	Max. operating temperature

Note

Artikel	Manufacturer	Series	Form Factor	Memory Type	Interface	Capacity	Write Performance	Read Performance	Operating Voltage	MTBF	Shock Resistance	Vibration Resistance	Industrie	Medical	Military	Power Loss Protection	Length	Width	Heigth	Min. operating temperature	Max. operating temperature
FCCB001TBC-EC00 PCIe - U.2 SSD HIX 1TB 3D-NAND TLC Commercial	Flexxon	HIX	U.2	3D TLC	NVMe PCIe Gen3 x4	1000 GB	3000 MB/s	3200 MB/s	12 V	2000000	1500G/0.5ms	80Hz ~ 2000Hz/20G	No	No	No	No	100 mm	69.85 mm	7 mm	- °C	70 °C
FCCB002TBC-EC00 PCIe - U.2 SSD HIX 2TB 3D-NAND TLC Commercial	Flexxon	HIX	U.2	3D TLC	NVMe PCIe Gen3 x4	2000 GB	2800 MB/s	3200 MB/s	12 V	2000000	1500G/0.5ms	80Hz ~ 2000Hz/20G	No	No	No	No	100 mm	69.85 mm	7 mm	- °C	70 °C
FCCB004TBC-EC00 PCIe - U.2 SSD HIX 4TB 3D-NAND TLC Commercial	Flexxon	HIX	U.2	3D TLC	NVMe PCIe Gen3 x4	4000 GB	2800 MB/s	3200 MB/s	12 V	2000000	1500G/0.5ms	80Hz ~ 2000Hz/20G	No	No	No	No	100 mm	69.85 mm	7 mm	- °C	70 °C
FCCB008TBC-EC00 PCIe - U.2 SSD HIX 8TB 3D-NAND TLC Commercial	Flexxon	HIX	U.2	3D TLC	NVMe PCIe Gen3 x4	8000 GB	2800 MB/s	3200 MB/s	12 V	2000000	1500G/0.5ms	80Hz ~ 2000Hz/20G	No	No	No	No	100 mm	69.85 mm	7 mm	- °C	70 °C
FCCB015TBC-LA00 Supreme SSD PCIe U.2 15TB	Flexxon	Supreme	U.2	3D NAND	NVMe PCIe Gen3 x4	15000 GB	2200 MB/s	3300 MB/s	-	2000000	1500G/0.5ms	80Hz ~ 2000Hz/20G	No	No	No	No	100.2 mm	70 mm	15 mm	- °C	70 °C
FCCB1920BC-EC00 PCIe - U.2 SSD HIX 1920GB 3D-NAND TLC Commercial	Flexxon	HIX	U.2	3D TLC	NVMe PCIe Gen3 x4	1920 GB	2800 MB/s	3200 MB/s	12 V	2000000	1500G/0.5ms	80Hz ~ 2000Hz/20G	No	No	No	No	100 mm	69.85 mm	7 mm	- °C	70 °C
FCCB1920BE-EC0S PCIe - U.2 SSD HIX 1920GB 3D-NAND TLC Diamond	Flexxon	HIX	U.2	3D TLC	NVMe PCIe Gen3 x4	1920 GB	3055 MB/s	3465 MB/s	12 V	2000000	1500G/0.5ms	80Hz ~ 2000Hz/20G	Yes	No	No	No	100 mm	69.85 mm	7 mm	-40 °C	85 °C
FCCB1920BS-EC0S PCIe - U.2 SSD HIX 1920GB 3D-NAND TLC Silver	Flexxon	HIX	U.2	3D TLC	NVMe PCIe Gen3 x4	1920 GB	3055 MB/s	3465 MB/s	12 V	2000000	1500G/0.5ms	80Hz ~ 2000Hz/20G	Yes	No	No	No	100 mm	69.85 mm	7 mm	- °C	70 °C
FCCB240GBE-EC0S PCIe - U.2 SSD HIX 240GB 3D-NAND TLC Diamond	Flexxon	HIX	U.2	3D TLC	NVMe PCIe Gen3 x4	240 GB	1000 MB/s	3000 MB/s	12 V	2000000	1500G/0.5ms	80Hz ~ 2000Hz/20G	Yes	No	No	No	100 mm	69.85 mm	7 mm	-40 °C	85 °C
FCCB240GBS-EC0S PCIe - U.2 SSD HIX 240GB 3D-NAND TLC Silver	Flexxon	HIX	U.2	3D TLC	NVMe PCIe Gen3 x4	240 GB	1000 MB/s	3000 MB/s	12 V	2000000	1500G/0.5ms	80Hz ~ 2000Hz/20G	Yes	No	No	No	100 mm	69.85 mm	7 mm	- °C	70 °C
FCCB3840BC-EC00 PCIe - U.2 SSD HIX 3840GB 3D-NAND TLC Commercial	Flexxon	HIX	U.2	3D TLC	NVMe PCIe Gen3 x4	3840 GB	2800 MB/s	3200 MB/s	12 V	2000000	1500G/0.5ms	80Hz ~ 2000Hz/20G	No	No	No	No	100 mm	69.85 mm	7 mm	- °C	70 °C
FCCB3840BE-EC0S PCIe - U.2 SSD HIX 3840GB 3D-NAND TLC Diamond	Flexxon	HIX	U.2	3D TLC	NVMe PCIe Gen3 x4	3840 GB	2980 MB/s	3390 MB/s	12 V	2000000	1500G/0.5ms	80Hz ~ 2000Hz/20G	Yes	No	No	No	100 mm	69.85 mm	7 mm	-40 °C	85 °C

Hint: current revision of the supplier datasheet is applicable

Design-In Support

Do you have questions about our NVMe SSDs products or are you looking for alternatives? As an authorized distributor, we maintain a very close exchange with our manufacturers and will be happy to advise you on the selection of suitable components and possible adaptations with our many years of experience. Talk to us!
