LED Module | 560x18 mm | 5000 K | 23 W | CRI 95
Binning: 3 stepLED placement: 1x72 3030 Sunlike Color: Cool White Voltage: 26 VDC Typ: Full Spectrum/Sunlike LED Module ZHAGA |
|
Manufacturer: | Seoul Semiconductor | |
Productgroup: | LED Modules | |
Part Number: | SMJD-2423072G-XXN1/3C | |
Series: | SunLike-Module | |
Datasheet: | Open datasheet | |
State: | 🟢 Active |
Note article Request article |
style: | DC LED Module | ||
No. of LEDs: | 72 | ||
color: | Cool White | ||
CCT : | 5000 K | ||
luminous flux : | 2200 lm | ||
CRI: | 95 | ||
supply voltage : | 26 V | ||
driving curent : | 900 mA | ||
driving mode: | Constant Current | ||
Zhaga: | Yes | ||
ZHAGA Book: | 7 | ||
connection: | SMD Terminal | ||
Length: | 560 mm | ||
Width: | 18 mm | ||
Heigth: | 5.4 mm | ||
Min. operating temperature: | -30 °C | ||
Max. operating temperature: | 85 °C |
|
Hint: current revision of the supplier datasheet is applicable
